Chalion QH Series(300HP, 4wd) Wheeled Tractor

Chalion 300HP farm tractor with Shangchai six cylinder engine, turbocharger, inter-cooling, 12 hours rated power: 221kw, fully enclosed drive cabin, air heater, air conditioner, self developed Transmission, 16F+4R gears, synchronizer shift, unit frame chassis, driving system with modularized structure, famous international brand front axle，construction machinery rear axle, caliper disc brake, power output shaft rotation speed: 540/1000 r/min, fully hydraulic front wheel steering, three groups of single/dual action hydraulic output, plough depth control method by position, floating control, and suspension mechanism of rear-mounted Category III.

info@qln-tractor.com 8618236900192
Send Email Inquiry Now
Product Description Product Parameters Related Products

Products Description

Chalion 300HP farm tractor with Shangchai six cylinder engine, turbocharger, inter-cooling, 12 hours rated power: 221kw, fully enclosed drive cabin, air heater, air conditioner, self developed Transmission, 16F+4R gears, synchronizer shift, unit frame chassis, driving system with modularized structure, famous international brand front axle，construction machinery rear axle, caliper disc brake, power output shaft rotation speed: 540/1000 r/min, fully hydraulic front wheel steering, three groups of single/dual action hydraulic output, plough depth control method by position, floating control, and suspension mechanism of rear-mounted Category III.


Products Advantage



  • Shangchai six cylinder engine, turbocharger, inter-cooling, 12 hours, fully enclosed drive cabin, air heater, air conditioner, Fast Transmission, 16F+4R gears, synchronizer shift.

    +

  • Unit frame chassis, driving system with modularized structure and construction machinery rear axle ensure its working performance.

    +

  • Fully hydraulic front wheel steering, three groups of single/dual action hydraulic output, plough depth control method by position, floating control, and suspension mechanism of rear-mounted Category III.

    +

Products Parameters

Model

QLN 3004

Engine

Rated Power/speed

kW(HP)/r/min

221(300)/2200

Drive Type

/

4×4

Dimension(Length/Width/Height)

mm

5980/2890/3380

Wheel Base

mm

3050

Track(Front wheel)

mm

2160-2288

Track(Rear wheel)

mm

2236-2312

Min. Ground Clearance

mm

520

Machine Weight

kg

10200

Rated Traction Force

kN

60

Max. Traction Force

kN

90

No. of gears

16F+4R

Forward Gear

Speed

km/h

4-39

Reverse Gear

Speed

km/h

5-33

Tire Model

Front Tires

/

16.9R30

Rear Tires

/

20.8R42

Power-output shaft Type

/

Rear position, independent

power-output shaft Rated Speed

r/min

540/1000

Max. lifting force

kN

50
