Chalion Rice Harvester
Chalion 4LZ-5.2 vertical threshing rice combine harvester is for paddy filed works, it includes the process of cutting, threshing and cleaning. The advantages: unique design; compact structure; reliable; easy-to-operate; reasonable; Rice combine harvester exported to South-east Asian, Middle-east Asian, South America and Africa.
ProductsDescription
Chalion 4LZ-5.2 vertical threshing rice combine harvester is for paddy filed works, it includes the process of cutting, threshing and cleaning. The advantages: unique design; compact structure; reliable; easy-to-operate; reasonable; Rice combine harvester exported to South-east Asian, Middle-east Asian, South America and Africa.
1.2 / 2.2 meters cutting width, Big Hydraulic JDF80 gear box with 45cc HST, high efficiency.
2.102HP Brand Turbo-charged Diesel Engine with stronger power and low fuel consumption.
3.400/450/500/550*90*51mm extra wider and extended rubber track. Lower ground pressure, work in the wet field more stably
4.340mm Higher ground clearance and increase the height between chassis and the top of track, not easy to accumulate mud. better for passing in paddy field.
5.The longitudinal axial flow threshing cylinders is more efficient and adjustable front & rear large-area sieving plates ensure the grain more clean, less breakage and less loss.
6.Down-forward straw-discharging outlet for straws with shredding mechanism to get straw pieces back to fields. Convenient for gathering by baler machine.
7.Sided small grain tank of 0.3CBM and Big grain tank of 1.4CBM with 270° discharger auger & Air conditioned cab and sunshade at Option.
ProductsUse
When used for segmented harvesting, a grater picker is installed on the harvesting table to pick up the dried grain strips and complete the operations such as threshing, separation and cleaning.
Products Parameters
Main performance and technical specifications | |||
---|---|---|---|
Model | 4LZ-5.2 | ||
Dimension (Length*Width*Height) mm | 5100*2600*2950 | ||
Weight (kg) | 3200 | ||
Working efficiency (hm2/h) | 0.32~0.56 | ||
Cutter bar length (mm) | 2200 | ||
Feeding capacity (kg/s) | 4 | ||
Grain Tank Capacity(m³) | 1.3 | ||
Engine | Type | Water cool, four stroke, diesel engine | |
Model | Changchai 98HP | ||
Output/rpm (kw/rpm) | 72/2400 | ||
Fuel tank capacity (L) | 110L | ||
Crawler specification(width*pitch*No.of tooth) | 450mm*90mm*51/ 500mm*90mm*51 | ||
Traveling system | |||
Ground pressure (kpa) | 21 | ||
Ground clearance | 325mm | ||
Transmission | Mechanical gearbox +HST | ||
Threshing cylinder | Type | Axial flow, spike tooth(vertical thresh) | |
Working parts | |||
Diameter& length | 630mm*2000mm | ||
Cleaning | Vibrating sieve + fan+ double threshing style | ||
Steering method | Hydraulic assistant steering | ||
Fuel consumption (hm2/h) | Hydraulic assistant steering | ||
Working speed (km/h) | 21~36 | ||
Wet field passing | 1.5~6.9 | ||
Grain unloading method | Automatic discharging | ||
Total loss (%) | Rice≤3.0,Wheat≤1.2 | ||
Breakage rate (%) | Rice≤1.5,Wheat≤1 | ||
Impurity rate (%) | Rice≤2.0,Wheat≤2.0 |
